Compact Multiformat VFFS Machine With Integrated Multi Head Weigher
All in One – Compact Multiformat Vffs Machine With Integrated Multi Head Weigher – 3 Bag Types
The IRTA XM COMBI is designed for producers who require fast, demanding, varied and reliable packaging in a bag or container format. Be this Pillow Pack, Block Bottom or Gusseted Bag.
A very compact ALL-IN-ONE unit, delivered fully programmed and ready to perform precision packaging operations. Occupying only a small space, this machine more than covers your initial needs at start-up, it allows for easy manoeuvring and will adapt to virtually any market demand.
The IRTA XM COMBI comes factory prepared with the necessary space, fastenings, programming, and attachments to incorporate our rear label applicator.
Technical Data | |
Finish | Stainless steel AISI 316 |
Maximum output | 75 Cycles/min |
Measurements (mm) | 1390 x 2497 x 2727 mm |
Approximate weight | 1,100 kg |
Spool Width / Max Diameter | 580 / 350 mm |
Energy consumption | (Nominal Max. Value) 4.5 KVA |
Power supply | 230 / 400 Vca |
Encoder support | Yes Ethernet LAN Connection |
Type of protection | IP 65 |
Air Consumption | 12 Nl / Cycle |
Electronics
- Servo Drives Rockwell
- Pneumatics Festo
- Vacuum Pump Becker
- Motion and operational control Bus Ethernet
- Control over shafts with implemented motion functions
- Regulation of welding time, temperature and pressure
- Spool spindle 75 mm
- Film drag Belt drive with vacuum
- Rapid spool change-over system
