Automatic Horizontal Strapping Machine – Rev
Automatic horizontal strapping machine for pallets
The Bull automatic strapping machine is designed for high-speed horizontal strapping of palletised loads using PP or PET strap.
Built for reliability, flexibility, and low maintenance, the Bull provides fast and secure pallet strapping for a wide range of load sizes and applications. The machine can be configured with a fixed base or mobile carriage and offers advanced automation features to maximise productivity and ease of operation.
Its robust construction, intelligent software, and safety-focused design ensure consistent performance and long service life in demanding production environments.
- Extremely fast and reliable horizontal pallet strapping.
- Suitable for PP and PET strap with thermosealing technology.
- Available on a fixed base or mobile carriage configuration.
- Robust steel construction designed for low maintenance operation.
- Linear guide system with wear-resistant steel components.
- Anti-jamming strap guides for smooth strap feeding.
- Pneumatic bobbin holder for easier strap unwinding.
- Easy programming with intuitive 4.3” colour touch-screen interface.
- Advanced self-learning software functions for simplified operation.
- Variable tension control adjustable by recipe.
- Suitable for longitudinal and transversal pallet positioning.
- Crate compactor system for increased load stability.
- Strap centring device for accurate and aligned strapping.
- Optional motorised corner applicator for precise corner placement.
- Double corner magazine with automatic pallet height detection.
- Integrated safety systems including safety bumpers and optional photoelectric barriers.
- Capable of integration into fully automatic production lines.
- Remote assistance and Industry 4.0 integration available.
- Turbo-Strap option increases production speed by up to 30%.
Technical Features:
- 4.3” colour touch-screen control panel.
- R-Touch graphic interface with production statistics.
- Arch internal dimensions: 1480 x 1480 mm.
- Maximum arch height: 2700 mm.
- Strap width: 12 mm.
- Strap thickness: 0.65 mm to 0.80 mm.
- Minimum strapping height: 230 mm.
- Adjustable strap launch speed via inverter control.
- Production output dependent on selected programme configuration.
Optional Features:
- Motorised multi-format corner applicator.
- Mobile carriage system with up to 4 stations.
- Turbo-Strap high-speed package.
- Extra-Force tensioning system.
- Safety barriers with photosensors.
- Raised pallet line shim kit.
- Multiple mounting configurations available.
- SCADA system integration.
- Easy Remote teleassistance.
- Industry 4.0 interconnection compatibility.
